NOTE: Sold only as a set of two (2) trucks.
SIZE: 55
AXLE WIDTH: 8.5”
BOARD FIT: 8.50” - 8.75”
HANGER WIDTH: 5.8” (149mm)
HEIGHT: 2.1" (53mm)
WEIGHT: 13.981 oz (396g)
The ACE AF1 features game-changing performance without deviating from our original Ace geometry. The AF1 is carefully manufactured using our proprietary casting process. Years in development, the ACE AF1 has a 70% increase in the aluminum’s structural integrity, making it the strongest and longest lasting cast Skateboard Truck on the market.
• Manufactured with high-quality AA 356.2 alloy using our own proprietary casting method
• True T6 heat-treated baseplates and hangers
• SAE 4140 steel alloy axles, oversized to eliminate bearing wobble.
• Patent pending rethreading axle nuts - no more damaged axle ends!
• Durable Hand-poured 96a urethane pivot bushings for better response.
• Refined suspension for a cleaner turn.
• Top Bushing: 12mm tall | 91a hardness
• Bottom Bushing: Bottom 14mm tall | 86a hardness
• Machine-faced hanger ends for precise bearing contact.
• Each Skateboard Truck includes bonus red Axle Re-Theader Die
